Electrical Package Vibration Testing Equipment ASTM / ISTA Standard

Name: Electrical Package Vibration Testing Equipment ASTM ISTA Standard
Brand: Infinity Machine
Price: 1 USD

Electrical Package Vibration Testing Equipment ASTM / ISTA Standard Manufactures

Brand Name : Infinity Machine

Model Number : RS-V Series

Certification : CE, ISO

Place of Origin : Made in China

MOQ : 1 set

Price : Negotiable

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets per month

Delivery Time : Shipped in 15 days after payment

Packaging Details : Standard export wooden case with operation manual and video inside.

Rated Frequency range : 5-4500Hz, 5-4000Hz, 5-3000Hz

Rated displacement : 25mm

Voltage : 3∮ 380V±10% AC50Hz

Max Testing load : 70Kg, 120Kg, 200Kg

Table top size : ∮110mm, ∮150mm, ∮200mm,

Table weight : 320Kg, 450Kg, 630Kg, 940Kg

Max output power : 1KVA, 2KVA, 3KVA, 8KVA, 10KVA

Size of power amplifier : 720x545x1625mm

Contact Now

Electrical Package Vibration Measurement Instrument ASTM / ISTA Standard

Model: RS-V Series

Purpose:

RS-V electromagnetic vibration testers are perfect for the vibration testing for the household goods, electronic products, car parts, and portable equipments etc.

RS-V electromagnetic vibration testers can meet the testing standards such as MIL, ASTM, IEC, ISO,BS, JIS.

RS-V electromagnetic vibration testers have the big diameter moving coil, equipped with high strength direction guiding, so that can use all kinds of additional table to do different kind of parts and products testing, and can get good vibration transmissibility.

The testers can easily to fulfill the small parts testing need, including the transportation simulating testing, integrating vibration testing, and the earthquake simulating testing.

Specification:

Model		RS-V100	RS-V150	RS-V200	RS-V300	RS-V600	RS-V1000
System main spec	Rated sine vibration force (N)	980	1470	1960	2940	5880	9800
	Random thrust	980	1470	1960	2940	5880	9800
	Impact thrust (bmx)	1960	2940	3920	5880	11760	19600
	Rated Frequency range (Hz)	5-4500			5-4000	5-3000
	Rated Acceleration (m/s²) No-load	490	735	980			1176
	Rated speed(m/s)	1.75	1.15	1.75	1.1	1.5	1.8
	Rated displacement	25
	Max Testing load (Kg)	70			120	200	120
	Consumption power (KVA)	4.5		5.5	7.5	17	20
	Voltage (V)	3∮ 380V±10% AC50Hz
Vibration body	The weight of the moving parts (Kg)	2			2.7	5.6	8.3
	Table top size(mm)	∮110			∮150	∮200	∮200
	Table weight(Kg)	320			450	630	940
	Table size (LxWxH) (mm)	660x550x650			720x550 x650	790x680 x660	830x690 x825
Power amplifier	Max output power(KVA)	1		2	3	8	10
	Weight of Power amplifier (Kg)	210		230	240	310	340
	Size of power amplifie (LxWxH)	720x545x1625
Vibration controller( Optional)		SDVC-2 SDVC-3 RDVC-2 RDVC-3
Cooling method		Wind cooling
Standard application		IEC68-2-6, GB/T13310-1991, GB/T2423.10
Horizon sliding table (Optional)		See below

Optional Horizon sliding table:

Model	Table outside size(mm)	The upper limit frequenct(Hz)	Table weight(Kg)
Rs0303	300x300x30	2000	8.3
Rs0404	400x400x32	1800	15.6
Rs0505	500x500x25	1000	18.5
Rs0606	600x600x35	2000	26.1
Rs0707	700x700x35	1500	48.8
Rs0808	800x800x45	2000	83.5
Rs1010	1000x1000x50	1500	144.6
Rs1212	1200x1200x50	1200	204
Rs1515	1500x1500x50	1200	320
Rs2020	2000x2000x50	500	564
Comments	If there are special requirement for the horizon sliding table, we can do the custom-making.
