Product Description:
The Micro Electro-hydraulic Servo Compression Testing Machine product has a test force measurement range of 4%-100%FS KN. This range makes it suitable for testing a wide range of materials, from soft plastics to hard metals. The maximum spacing between upper and lower plates is 370mm, which means that it can accommodate large specimens for testing.
The Software Interface of the Micro Electro-hydraulic Servo Compression Testing Machine product has the function of test force, peak value, sample deformation, piston displacement, and test curve. These functions make it easy to monitor the testing process and obtain accurate test results. The test curve function allows the user to view the testing data in real-time, which can help them to identify any issues with the specimen being tested.
One of the key features of the Micro Electro-hydraulic Servo Compression Testing Machine product is its Full Digital Closed-loop Measurement and Control System. This system ensures that the test results are accurate and reliable. It also allows the machine to maintain a constant load over a long period of time, which is essential for testing materials that require a constant load.
The Micro Electro-hydraulic Servo Compression Testing Machine product is designed to be user-friendly. Sample information input is convenient, and the same condition of sample information once input can complete the test of multiple samples. This feature saves time and reduces the risk of error.
In conclusion, the Micro Electro-hydraulic Servo Compression Testing Machine product is a Precision Compression Testing Equipment that is suitable for testing a wide range of materials. Its Full Digital Closed-loop Measurement and Control System ensures that the test results are accurate and reliable. Its user-friendly design makes it easy to use and saves time.
Features:
- Product Name: Micro Electro-hydraulic Servo Compression Testing Machine
- Piston stroke: 50mm
- The Main Engine Adopts Two Columns Of High Rigid Frame Structure, With Stable Support And Beautiful Appearance.
- It Has The Control Functions Of Constant Velocity Stress, Constant Velocity Strain, Constant Velocity Test Force, Constant Velocity Displacement, Test Force Retention, Displacement Retention, Etc.
- Precision Compression Testing Equipment
- The Measurement And Control System Has Fast Operation Speed, Mild Interface, And A Variety Of Sample Information Input Modes, Which Can Meet The Test Of Different Materials;
- Micro Electro-hydraulic Servo Compression Testing Machine
- Samples With The Same Conditions Can Be Superposition Of Various Test Curves, Can Clearly Identify The Stability Of The Material;
Technical Parameters:
| Product Name: | Micro Electro-hydraulic Servo Compression Testing Machine |
| Piston Diameter: | φ130mm |
| Size of Upper and Lower Pressure Plate: | 216mm*216mm |
| Test Force Measurement Range: | 4%-100%FS KN |
| Weight of Equipment: | About 600 |
| Feature: | Automatic Overload Protection Shutdown When The Load Exceeds 3-5% Of The Full Range. |
| Resolution of Test Force: | 0.01kN |
| Feature: | The Test Space Was Adjusted By Adding Pad Blocks.(Block Specification: 30mm 50mm90mm Negotiated By Both Parties) |
| Maximum Test Force: | 300kN |
| Feature: | Full Digital Closed-loop Measurement And Control System, Can Realize The Equal Load Loading And Long-time Load Maintenance Function. |
Applications:
The Infinity Machine IF703 is a Micro Electro-hydraulic Servo Compression Testing Machine that is a precision compression testing equipment. Made in China, this machine is certified with CE and ISO. It has a minimum order quantity of 1 and the price is negotiable. The packaging details include clear sheet, sponge, and wood carton. The delivery time for this machine is 20-30 days after order confirmation.
The payment terms include TT, PayPal, Moneygram, and other options. This machine has a supply ability of 200 sets per month.
The main engine of the IF703 Micro Electro-hydraulic Servo Compression Testing Machine adopts two columns of high rigid frame structure, providing stable support and a beautiful appearance. The hydraulic pump has a rated pressure of 25MPa. The relative error of the test force indication value is ±1% of the indicated value.
This equipment is used for the compression test of a variety of materials such as cement, concrete, various building bricks, rubber pads, concrete components, metal components, and other compressive strength tests. The software has dozens of standard methods, and users can also compile their own applications of standard methods. Samples with the same conditions can be superimposed with various test curves, and can clearly identify the stability of the material.
The IF703 Micro Electro-hydraulic Servo Compression Testing Machine is suitable for a variety of application occasions and scenarios, such as:
- Research and development laboratories
- Quality control departments
- Universities and colleges
- Materials production facilities
This machine is ideal for testing the compressive strength of materials and can be used in a range of industries such as construction, manufacturing, and research. Whether you need to test cement, concrete, building bricks, or other materials, the IF703 can provide you with accurate results.
Customization:
One of the features of the Micro Electro-hydraulic Servo Compression Testing Machine is that the Main Engine adopts two columns of high-rigid frame structure, with stable support and beautiful appearance. Samples with the same conditions can be superposition of various test curves, which can clearly identify the stability of the material. The hydraulic pump rated pressure is 25MPa, and the relative error of the test force indication value is within ±1% of the indicated value.
Support and Services:
The Micro Electro-hydraulic Servo Compression Testing Machine is a highly advanced and versatile testing instrument used to evaluate the mechanical properties of a wide range of materials. Our product technical support and services include:
- Installation and commissioning of the machine
- On-site training for operators and technicians
- Regular maintenance and calibration services
- Troubleshooting and repair services
- Upgrades and retrofitting to ensure the machine stays up-to-date with the latest technology
- Technical consultation for any questions or concerns regarding the machine
Packing and Shipping:
Product Packaging:
- The Micro Electro-hydraulic Servo Compression Testing Machine will be securely packed in a wooden crate to prevent any damage during transportation.
- All necessary accessories will be included in the package.
- The package will be labeled with the product name, quantity, and any handling instructions.
Shipping:
- The Micro Electro-hydraulic Servo Compression Testing Machine will be shipped via a reputable shipping company to ensure timely delivery and safe handling.
- The shipping cost will be calculated based on the destination and the weight of the package.
- A tracking number will be provided to the customer to track the shipment.
- The customer is responsible for any customs duties or taxes that may apply.
FAQ:
Q1: What is the brand name of this testing machine?
A1: The brand name of this testing machine is Infinity Machine.
Q2: What is the model number of this testing machine?
A2: The model number of this testing machine is IF703.
Q3: Where is this testing machine made?
A3: This testing machine is made in China.
Q4: What certifications does this testing machine have?
A4: This testing machine has CE and ISO certifications.
Q5: What is the minimum order quantity for this testing machine?
A5: The minimum order quantity for this testing machine is 1.
Q6: What is the price of this testing machine?
A6: The price of this testing machine is negotiable.
Q7: What are the packaging details of this testing machine?
A7: The packaging details of this testing machine include clear sheet, sponge, and a wood carton.
Q8: What is the delivery time for this testing machine?
A8: The delivery time for this testing machine is 20-30 days after order confirmed.
Q9: What are the payment terms for this testing machine?
A9: The payment terms for this testing machine include TT, PayPal, Moneygram, and so on.
Q10: What is the supply ability for this testing machine?
A10: The supply ability for this testing machine is 200 sets per month.
